Chapter 7 Parameters
65
1
1
Internal Torque4(FA67)
Note: 0=OFF, 1=ON
33
The input
direction
of analog
torque
command
Reverse the input polarity of analog torque.
0-1
0
34
Internal
CCW
torque
limit
1.The setting value is the percentage of rated
torque.For example,it is set to 2 times of the rated
torque, the value is 200.
2. At any time, this restriction is valid.
3. If the setting value is over than the max overload
capacity, the actual torque limit is the max overload
capacity that is permitted.
0-300%
300
35
Internal
CW torque
limit
1.The setting value is the percentage of rated
torque.For example,it is set to 2 times of the rated
torque, the value is 200.
2. At any time, this restriction is valid.
3. If the setting value is over than the max overload
capacity, the actual torque limit is the max overload
capacity that is permitted.
-300-0%
-300
36
External
CCW
torque
limit
1.The setting value is the percentage of rated torque,
for example, it is set to 1 time of rated torque, the
value is 100.
2.Only when the input terminal(FIL) of CCW torque
limit is ON is it valid.
3.When the limit is valid, the actual torque limit is
the Minimum value of max overload
capacity ,internal CCW torque limit and external
CCW torque limit.
0-300%
100
37
External
CW torque
limit
Set external torque limit of the motor CW direction.
1.The setting value is the percentage of rated torque,
for example, it is set to 1 time of rated torque, the
-300-0%
-100
