Chapter 7 Parameters
69
0, it means the input terminal dose not reverse.
While it is 1, it means the terminal reverses.
The binary digit represents the input terminals as
following:
3
2
1
0
DI4
DI3
DI2
DI1
0: high level is active.
1: low level is active.
57
Effective
level
control
word of
output
terminals
1.To reverse the output terminals. For reversed
terminals,the definitions of breaking over and
cut-off is contrary to standard definitions
2.Represented by a binary digit of 4 bits. If it is
0, it means the input terminal dose not reverse.
While it is 1, it means the terminal reverses.
The binary digit represents the input terminals as
following:
3
2
1
0
DO4
DO3
DO2
DO1
0: high level is active.
1: low level is active.
0000-1111
0000
58
Removing
jitter time
constant
of I/O
input
terminal
1.Set the removing jitter filter time for input
terminal.
2.The value is smaller, the terminal input
response frequency is quicker.
3.The value is bigger, the anti-jamming
performance of input terminal is better, but the
response frequency becomes slow.
1-20ms
2
59
Effective
command
pulse edge
Set to:
0: the rising edge is effective.
1:the falling edge is effective.
0-1
0
60
Soft reset
Set to:
0:Soft reset is invalid.
0-1
0
