Coolmay C600S - Page 96

Chapter 7 Parameters
90
F4-12
The pulse
number
setting in
position loop
of internal
position
instruction 4
1. To set the position pulses of the 4
th
stage internal
position.
2. Internal position instruction 4=the position
cycles setting of the 4
th
internal position+the pulse
number setting of the 4
th
internal position.
+/-max.
cnt/rev
0
F4-13
The move
speed of
internal
position
instruction 4
To set the move speed of internal position instruction 4.
0-5000
r/min
1000
F4-14
The position
cycles of
internal
position
instruction 5
To set the position cycles of the 5
th
stage internal
position instruction.
-30000-
30000
0
F4-15
The pulse
number
setting in
position loop
of internal
position
instruction 5
1. To set the position pulses of the 5
th
stage internal
position.
2. Internal position instruction 3=the position
cycles setting of the 5
th
internal position+the pulse
number setting of the third internal position.
+/-max.
cnt/rev
0
F4-16
The move
speed of
internal
position
instruction 5
To set the move speed of internal position
instruction 5.
0-5000
r/min
1000
