Coolmay C600S - Page 97

Chapter 7 Parameters
91
F4-17
The number
of position
cycles of
internal
position
instruction 6
To set the number of position cycles of the sixth
stage internal position.
-30000-
30000
0
F4-18
The pulse
number
setting in
position loop
of internal
position
instruction 6
1. To set the position pulses of the 6
th
stage internal
position.
2. Internal position instruction 6=the position
cycles setting of the 6
th
internal position+the pulse
number setting of the 6
th
internal position.
+/-max.
cnt/rev
0
F4-19
The position
cycles of
internal
position
instruction 7
To set the position cycles of the 7
th
stage internal
position instruction.
0-5000
r/min
1000
F4-20
The position
cycles of
internal
position
instruction 7
To set the position cycles of the 7
th
stage internal
position instruction.
-30000-
30000
0
F4-21
The pulse
number
setting in
position loop
of internal
position
instruction 7
1. To set the position pulses of the 7
th
stage internal
position.
2. Internal position instruction 7=the position
cycles setting of the 7
th
internal position+the pulse
number setting of the 7
th
internal position.
+/-max.
cnt/rev
0
