Chapter 7 Parameters
92
F4-22
The move
speed of
internal
position
instruction 7
To set the move speed of internal position instruction 7.
0-5000
r/min
1000
F4-23
The number
of position
cycles of
internal
position
instruction 8
To set the number of position cycles of the eighth
stage internal position.
-30000-
30000
0
F4-24
The pulse
number setting
in position
loop of internal
position
instruction 8
1. To set the position pulses of the 8
th
stage internal
position.
2. Internal position instruction 8=the position
cycles setting of the 8
th
internal position+the pulse
number setting of the 8
th
internal position.
+/-max.
cnt/rev
0
F4-25
The move
speed of
internal
position
instruction 8
To set the move speed of internal position instruction 8.
0-5000
r/min
1000
F4-32
The type of
origin detector
and setting of
finding
direction
0: Forward direction origin regression and CCWL is
as regression origin.
1: Reverse direction origin regression and CWL is
as regression origin.
2: Forward direction origin regression and ORGP is
as regression origin.
3: Reverse direction origin regression and ORGP is
as regression origin.
4: Forward looking for Z pulse as the origin of
regression.
5: Reverse looking for Z pulse as the origin of
0-5
0
