Artiglio Master Code User Manual 41
UK
Always verify the presence and size of the sensor on the inflation valve in order to
assess the possibility of operating in automatic mode. Alternatively, you can proceed
manually.
NOTICE
PHASE 2: Press the icon (Fig. 31b) to be-
gin top bead breaking. Wheel rotation, lowering of the
disc, penetration and if present (optional) lubrication
to aid in detaching the bead from the rim seat will be
activated automatically.
Alternatively, manually lubricate the head to make
bead breaking easier.
In the event that bead breaking is unsuccessful, repeat the automatic phase press-
ing the icon
(Fig. 31b) or proceed manually.
NOTICE
PHASE 3: At the end of phase 2 bottom bead breaking
will be automatically activated (Fig. 31c). Positioning
of the disc, penetration, wheel rotation and if present
(optional) lubrication to aid in detaching the bead
from the rim seat will be activated automatically.
Alternatively, manually lubricate the head to make
bead breaking easier.
If present (optional) the camera that shows the bottom
bead breaking phase is activated (Fig. 31d). For correct
camera use, see section 6.2.
Use the mirror or the camera (optional) to verify that the bottom bead breaker disc
is correctly positioned above the rim shoulder (Fig. 31d). Alternatively, interrupt
the sequence by pressing the stop button.
NOTICE
31b
31c
31d
