42 Artiglio Master Code User Manual
In the event that bead breaking is unsuccessful, repeat the automatic phase press-
ing the icon
(Fig. 31c) or proceed manually.
NOTICE
PHASE 4: At the end of phase 3 the demounting phase
will automatically be activated (Fig. 31e).
The machine movements differ as indicated below in order to better operate on
the various types of tyres.
NOTICE
NORMAL, RFT-UHP and SOFT
Top bead demounting.
During this operation ensure:
a. correct hooking of the bead during search for the
same (Fig. 31f).
b. Correct height positioning of the tool based on the
type of tyre to be demounted (Fig. 31g).
c. Correct positioning of the bead in the channel (Figs.
31g and 31h).
N.B.: During RFT-UHP tyre demounting handling the
display indicates use of the bead presser at 6 o’clock
in order to facilitate insertion of the bead into the
channel (Fig. 31i)
.
31e
31f
31g
31h
31i
