Artiglio Master Code User Manual 43
UK
In the event that one or more operations are not completed correctly, repeat the
automatic phase pressing the icon
(Fig. 31e) or proceed manually.
NOTICE
Wheel rotation activates automatically in order to complete extraction of the top bead.
Bottom bead demounting using only the bottom bead breaker disc. .
During this operation ensure:
a. correct hooking of the bead during lifting of the tyre (Fig. 31l).
b. Correct positioning of the bottom bead inside the channel on the side opposite the
bead breaker disc (Fig. 31m).
31l
31m
Where necessary, during the bottom bead breaker raising phase, for extraction of
the bottom bead, keep the tyre raised with your hand (Fig. 31n).
NOTICE
c. That the bead breaker disc has correctly taken the
bottom bead above the top edge of the rim (Fig. 31n).
d. correct penetration of the disc for extraction of the
bottom bead. (Fig. 31n).
31n
