48 Artiglio Master Code User Manual
- manually adjust the tyre so that part of the bottom bead is correctly inserted into the channel
(Figs. 32b - 32c).
PHASE 6: Press the icon
(Fig. 32d) to activate
the bottom bead mounting sequence
.
Maintain a light pressure on the tyre section with the lower bead not yet inserted
in the rim.
NOTICE
After mounting the first bead the machine po-
sitions the fixed tool and the top bead breaker
on the upper part of the tyre in the correct
top bead mounting position. (Fig. 32e).
NOTICE
The top bead breaker automatically hooks during the descent phase.
32c
32b
32d
32e
WARNING
