Artiglio Master Code User Manual 53
UK
2 - Press the top bead breaker disc penetration button .
3 - If available (optional), press the button
to carry out lubrication and facilitate
bead detachment.
Alternatively, manually lubricate the head to make
bead breaking easier.
4 - Press the pedal
to turn the turntable.
5 - Operate the control
, tapping on it, to lower
the bead breaker disc and fully remove the bead from
its seat on the rim.
6- Turn at least one rotation to finish bead breaking.
THESE OPERATIONS will completely detach the top
bead from the rim (see Fig. 35b).
7 - Move the lever
upward to automatically
stop penetration and to withdraw the disc from the work area.
When the upper bead breaking unit reaches the upper
travel limit, the tilting arm is automatically
released upwards (Fig. 35c).
CAUTION
35c
35a
35b
