54 Artiglio Master Code User Manual
8 - Act on the lever
and move the disc, tak-
ing it to about 5 mm above the rim edge (Fig. 35d).
In this phase the camera can be activated (optional)
in order to obtain maximum control.
If available (optional), press the button
and the camera will display the bottom part of
the tyre (Fig. 35e).
For correct camera use, see section 6.2.
9 - Press the button to activate penetra-
tion of the bottom bead breaker disc.
10 - If available (optional), press the button
to carry out lubrication and facilitate
bead detachment.
Alternatively, manually lubricate the head to make bead breaking easier.
11 - Press the pedal
to turn the turntable.
12 - Operate the control
, tapping on it, to raise the bead breaker disc and fully
remove the bead from its seat on the rim.
13- Turn at least one rotation to finish bead breaking.
THESE LAST OPERATIONS will completely detach the bottom bead from the rim.
14 - Move the lever
downward to automatically stop penetration and to withdraw
the disc from the work area.
DEMOUNTING
1 - Act on the lever to insert the movable tool
completely under the bead (Fig. 36a).
35d
35e
