Artiglio Master Code User Manual 55
UK
To obtain a more precise position, press the button located
on the top part of the lever
during movement
(Fig. 36b).
3 - Hold in the button
to hook the bead (Fig. 36c).
Rotate the wheel applying pressure on the pedal
.
If necessary, operate the control to lower the head
further
.
4 - After hooking the bead, release the button
to return the tool to the rest position (Fig. 36d).
5 -
raise the movable tool so that the
horizontal line of the tool is not completely visible
(Fig. 36e) - (A, Fig. 36f).
6 - Ensure that the bottom part of the tyre is completely
bead broken, otherwise repeat the bottom bead break-
ing operation.
7 - Ensure that the bead at 180° with respect to the tool
is in the channel, otherwise use the bead pressing tool
to facilitate positioning (Fig. 36g).
36a
36b
36d
36e
36c
36f
A
