56 Artiglio Master Code User Manual
8 - Turn the selector (see Fig. 36h).
9 - Keeping the selector turned , press the
pedal
to turn the turntable and demount
the upper part of the tyre from the rim.
If necessary, operate the control
to slightly raise
the head and complete top bead removal.
10 - Release the selector
and the pedal
11 - Withdraw the movable tool from the work area
.
12 - Press the icon on the display to en-
able tool positioning in the lower par (Fig. 36i).
The machine will position the fixed tool in the tyre underside and at the same time the
bead breaker will move upwards to provide the space necessary to load the bead.
NOTICE
13 - Manually position the tyre so that the tool hook
is between the lower bead and the rim (Fig. 36l).
36h
36g
36i
36l
