Artiglio Master Code User Manual 57
UK
14 - Press the icon on the display (Fig. 36m).
The fixed tool will go into position to remove the
lower bead (Fig. 36n).
For some types of wheels/rims, the height of the
tool may need to be manually adjusted, operating
on the control
.
15 - After completing the operation the machine au-
tomatically suggests the next operating sequence.
16 - Act on the lever
to move the bottom
bead breaker disc upward (Figs. 36o - 36p) until
reaching 5 mm above the top edge of the rim.
17 - Press the button to activate penetra-
tion of the bottom bead breaker and the pedal
to turn the turntable.
18- If necessary, operate the control
to
slightly lift the bottom bead breaker disc.
36n
36o
36p
36m
