Cornelius FCB POST-MIX DISPENSER - Figure 1. Four-Flavor Dispenser; Table 1. Design Data

22813
FIGURE 1. FOUR-FLAVOR DISPENSER
Table 1. Design Data
Unit Part Numbers:
60 HZ Units:
Two-Flavor Unit (Air-Cooled) 416220
Two-Flavor Unit (Water-Cooled) 416222
Four-Flavor Unit (Air-Cooled) 416200
Four-Flavor Unit (Water-Cooled) 416202
50 HZ Units:
Two-Flavor Unit (Air-Cooled) 496220
Two-Flavor Unit (Water-Cooled) 496222
Four-Flavor Unit (Air-Cooled) 496200
Four-Flavor Unit (Water-Cooled) 496202
Overall Dimensions:
Two-Flavor Units:
Height
Width
Depth (W/O Drip Tray)
Depth (W/Drip Tray)
60-1/2 inches
19-1/4 inches
32-1/2 inches
38 inches
Four-Flavor Units:
Height 60–1/2 inches
Width 32-1/2 inches
Depth (W/O Drip Tray) 32-1/2 inches
Depth (W/Drip Tray) 38 inches
Shipping Weight (approx)
Two-Flavor Units 466 pounds
Four-Flavor Units 800 pounds
Compressor Horsepower 2 H.P.
