Cornelius FCB POST-MIX DISPENSER - Figure 7. Unit Internal Components

342813
PRODUCT BLENDER
TANK (2)
UPPER CONTROL
BOX COVER
UPPER CONTROL BOX COVER
RETAINING SCREW (4)
FAULT MESSAGE
DISPLAY
FREEZE CYLINDER (2)
SECONDARY CO
2
REGULATOR (3)
RECEIVER TANK
CONDENSER COIL
RELIEF VALVE (2)
SYRUP FLOW REGULATOR (2)
BEATER DRIVE
MOTOR (2)
CARBONATED WATER
FLOW REGULATOR (2)
REFRIGERATION
COMPRESSOR
LOWER CONTROL
BOX
PRODUCT BLENDER
TANK (2)
UPPER CONTROL
BOX COVER
UPPER CONTROL BOX COVER
RETAINING SCREW (4)
FAULT MESSAGE
DISPLAY
FREEZE CYLINDER (2)
SECONDARY CO
2
REGULATOR (3)
RECEIVER TANK
RELIEF VALVE (2)
SYRUP FLOW REGULATOR (2)
BEATER DRIVE
MOTOR (2)
CARBONATED WATER
FLOW REGULATOR (2)
REFRIGERATION
COMPRESSOR
LOWER CONTROL
BOX
WATER BOOSTER
COIL
ACCUMULATOR
ACCUMULATOR
TWO-FLAVOR UNIT (AIR-COOLED) SHOWN
TWO-FLAVOR UNIT (WATER-COOLED) SHOWN
AIR FILTER
FIGURE 7. UNIT INTERNAL COMPONENTS
