ITEMS AFFECTED BY ERROR
MESSAGE
DISPLAYED
ERROR
BEATER
MOTOR 1
BEATER
MOTOR 2 REFRIG 1 REFRIG 2
Motor 1 Low Current, < 109,
Sensed on motor one
OFF OFF
Motor 2 Low Current, < 109,
Sensed on motor two
OFF OFF
Motor 1 High Current, > 255,
Sensed on motor one
OFF OFF
Motor 2 High Current, > 255,
Sensed on motor two
OFF OFF
REFRIG ** Maximum Run Time on compressor OFF OFF OFF OFF
SYRUP 1 Syrup Out Side One OFF
SYRUP 2 Syrup Out Side Two OFF
CO
2
OUT CO
2
Out OFF OFF
H
2
O H
2
O Out *OFF *OFF
SENSOR 1 Temp Sensor Inlet One OFF OFF OFF OFF
SENSOR 2 Temp Sensor Inlet Two OFF OFF OFF OFF
SENSOR 3 Temp Sensor Outlet OFF OFF OFF OFF
* The refrigeration system and carbonator shall continue to operate for 1.5 minutes after a water pressure loss
has been detected. If water pressure loss continues beyond 1.5 minutes, the refrigeration system and
carbonator will stop.
** 25 minutes on Standard System, 30 minutes on Remote System.
TABLE 9. DISPLAYED ERROR CONDITIONS
DISPLAYING ‘‘TOTALS’’ (DISPLAYED CYCLES AND HOURS TOTALS) ONTO MESSAGE
DISPLAY
(see Table 4 and Table 8).
‘‘TOTALS’’ (DISPLAYED CYCLES AND HOURS TOTALS) may be displayed on message display as follows:
1. Refer to PROGRAMMING MAIN MENU SELECTION ONTO MESSAGE DISPLAY and bring up the word
‘‘CLOCK’’ on message display.
2. Repeatedly press and release ‘‘CANCEL DEFROST’’ (ADVANCE) switch to advance through main menu
until ‘‘TOTALS’’ menu appears on message display. Press ‘‘DEFROST’’ (SELECT) switch to lock
‘‘TOTALS’’ menu in place. The word ‘‘COMP HRS’’ will appear on message display.
3. Press and hold ‘‘DEFROST’’ (SELECT) switch. Compressor run hours will appear on message display.
4. Press ‘‘CANCEL DEFROST’’ (ADVANCE) switch to advance and bring up ‘‘COMP CYC’’ on message
display.
5. Press and hold ‘‘DEFROST’’ (SELECT) switch. Compressor cycles x 100 will appear on message display.
6. Use CANCEL DEFROST (ADVANCE) switch to advance through remaining ‘‘TOTALS’’ (DISPLAYED
CYCLES AND HOURS TOTAL MENU) (see Table 8). Press ‘‘DEFROST’’ (SELECT) switch to obtain
message display readings of the individual menu selections.
7. Press ‘‘ERROR RESET’’ switch two times to exit from MENU SELECTIONS.
