Cornelius FCB POST-MIX DISPENSER - Figure 12. Water Strainer Screen and Double Liquid Check; Valve

57 2813
SCREEN RETAINER
O-RING (P/N 315349000)
SCREEN (P/N 315348000)
WATER PUMP MOTOR
DOUBLE LIQUID
CHECK VALVE ASS’Y
WHITE TAPERED
GASKET
WATER PRESSURE SWITCH
WATER PRESSURE
REGULATOR
WATER PUMP
SYRUP SOLD-OUT
FLOAT SWITCH (2)
SYRUP SOLENOID
VALVE (2)
CARBONATED WATER
FLOW REGULATOR (2)
LIQUID CHECK
VALVE (4)
CARBONATED WATER
SOLENOID VALVE (2)
SYRUP FLOW
REGULATOR (2)
FIGURE 12. WATER STRAINER SCREEN AND DOUBLE LIQUID CHECK VALVE
