45 2813
DISPLAYED MODEL HZ MOTOR DESCRIPTION
KLBER
–
60 Klauber 60 Over/under gear box with a GE wide-range voltage motor.
FASV3+60 Fasco/VW 60 Over/under gear box with a Fasco wide-range voltage motor.
FASCWR 60 Fasco/VW 60 Standard gear box using a Fasco wide-range voltage motor.
VW/GE 60 Fasco/VW 60 Standard gear box with a GE 219/242 volt motor.
BODINE 60 Bodine 60 Special wide-range motor.
EMRSN 60 Emerson 60 Over/under gear box with an Emerson wide-range motor.
KLBER
–
50 Klauber 50 Over/under gear box with a GE wide-range voltage motor.
FASV3+50 Fasco/VW 50 Over/under gear box with a Fasco wide-range voltage motor.
FASCWR 50 Fasco/VW 50 Standard gear box using a Fasco wide-range voltage motor.
VW/GE 50 Fasco/VW 50 Standard gear box with a GE 219/242 volt motor.
EMRSN 50 Emerson 50 Over/under gear box with an Emerson wide-range motor.
TABLE 6. MOTOR SELECT
DIP SWITCH
NO. 1
DIP SWITCH
NO. 2 *MESSAGE
OFF OFF “ENJOY A FROZEN BEVERAGE”
OFF ON NOT USED - BLANK
ON OFF “HAVE A NICE DAY”
ON ON “DISFRUTE UNA BEBIDA CONGELADA CARBONATADA”
*For special messages, contact your local sales representative.
TABLE 7. POINT OF SALE DISPLAY MESSAGES
Three point of sales display messages are available, and the desired one may be programmed in to appear on
the message display by placing No. 1 and No. 2 switches (see Figure 10 and Table 5 and Table 7) on the DIP
SWITCH ASSEMBLY in the appropriate positions.
ADJUSTING “VIS SET” (PRODUCT VISCOSITY) OF DISPENSED PRODUCT
Adjusting “VIS SET” (PRODUCT VISCOSITY) determines what product consistency of the dispensed product
will be present in each freeze cylinder. Adjust “VIS SET” (PRODUCT VISCOSITY) of the dispensed product as
follows.
1. Refer to PROGRAMMING MAIN MENU SELECTIONS INTO MESSAGE DISPLAY and bring up “VIS
SET” on message display.
2. Press “DEFROST” (SELECT) switch to bring up numbers on message display.
Note: The direction of arrows (% &) on message display indicates which set of numbers belongs to
which freeze cylinder. A No. 4 setting indicates the thinnest product consistency of dispensed product
and a No. 12 setting indicates the thickest consistency of product dispensed.
