TOP PANEL
Remove two screws securing top panel, then lift panel up off Unit.
LOWER FRONT ACCESS PANEL
Remove two screws securing lower front panel, then pull panel down to remove from Unit.
CONDENSER COIL ACCESS PANEL
Pull out on top of condenser coil access panel, then lift panel up and out to remove.
LUBRICATION
CARBONATOR(S) WATER PUMP(S) MOTOR(S)
(see Figure 12 )
Carbonator(s) water pump(s) motor(s) bearings must be lubricated periodically. Refer to oiling instructions on
motor. DO NOT OVER OIL.
SERVICING DISPENSING VALVES CAGED O-RINGS AND FREEZE CYLINDERS DRIVE
SHAFT/ SEAL ASSEMBLIES
Servicing Dispensing Valves Caged O-Rings.
(see Figure 8)
NOTE: Dispensing valves caged O-Rings should be serviced (lubricated) every six months and O-Rings
should be replaced once a year.
1. Defrost freeze cylinders, shut Unit down, disconnect electrical power from Unit, close product shutoff
valves in lines leading from the product blender tanks to the freeze cylinders, then drain product from the
freeze cylinders.
Note: Item numbers in parentheses in this paragraph are in reference to Figure 4.
2. Remove HEX NUTS (item 7) and FLATWASHERS (item 6) securing FACEPLATE (item 8) to freeze
cylinder, then remove faceplate from cylinder.
3. Carefully remove large O-RING (item 5) from FACEPLATE (item 8).
