TOTALS MENU COMMANDS DESCRIPTION
COMP HRS COMPRESSOR RUN HOURS
COMP CYC COMPRESSOR CYCLES X100
DFSTYC1 DEFROST SIDE 1 CYCLES
DFSTYC2 DEFROST SIDE 2 CYCLES
BLDRCYC1 BLENDER SIDE 1 CYCLES X100
BLDRCYC2 BLENDER SIDE 2 CYCLES X100
SOLDOUT 1 SOLDOUT SYRUP SIDE 1
SOLDOUT 2 SOLDOUT SYRUP SIDE 2
BMTRHRS1 BEATER MOTOR 1 HOURS
BMTRHRS2 BEATER MOTOR 2 HOURS
PWR ON POWER ON HOURS
AUTO ON 1 AUTO SIDE 1 HOURS
AUTO ON 2 AUTO SIDE 2 HOURS
ERR HRS 1 ERROR SIDE 1 HOURS
ERR HRS 2 ERROR SIDE 2 HOURS
SLEEP HRS SLEEP MODE HOURS
SYR MIN 1 (see note) SYRUP MINUTES (SIDE 1)
SYR MIN 2 (see note) SYRUP MINUTES (SIDE 2)
NOTE: Displaying “SYR MIN 1” or “SYR MIN 2” on message display will indicate time in minutes syrup
actually has been dispensed. Refer to table and formula below to calculate how much syrup has been
dispensed.
BRIX “A”
11.0 0.1358
11.5 0.1420
12.0 0.1481
12.5 0.1543
13.0 0.1605
13.5 0.1667
14.0 0.1728
14.5 0.1790
15.0 0.1852
15.5 0.1914
16.0 0.1975
GALLONS = “A” x SYRUP MINUTES
Using the table to the left, choose the “A” number
that corresponds to your BRIX setting. Multiply
the “A” number by the syrup minutes reading to
obtain the amount (gallons) of syrup used.
Note: “A” numbers are based upon a
4.4 to 1 water to syrup “ratio”.
TABLE 8. “TOTALS” (DISPLAYED CYCLES AND HOURS TOTALS) MENU
