Page 19
ZONE GROUP ARM/DISARM OPTIONS A
Zone Options A
P411E Zone Group #1 Options A Default 1,6,7 1 = Assigned to Area “A”
P412E Zone Group #2 Options A Default 1,6,7 2 = Assigned to Area “B”
P413E Zone Group #3 Options A Default 1,6,7 3 = Assigned to Area “C”
P414E Zone Group #4 Options A Default 1,6,7 4 = Assigned to Area “D”
P415E Zone Group #5 Options A Default 1,6,7 5 = Is a Stay Mode Zone
P416E Zone Group #6 Options A Default 1,6,7 6 = Can be Manually Bypassed
P417E Zone Group #7 Options A Default 1,6,7 7 = Can Auto-bypass
P418E Zone Group #8 Options A Default 1,6,7 8 = Is a Day Zone
P419E Zone Group #9 Options A Default 1,6,7
P420E Zone Group #10 Options A Default 1,6,7
Option 1 Assigned to Area “A”. The zone with this group # is in Area A. If in more than one area, all areas
assigned to the zone must be armed before it is in the armed state.
Option 2 Assigned to Area “B”. The zone with this group # is in Area B. If in more than one area, all areas
assigned to the zone must be armed before it is in the armed state.
Option 3 Assigned to Area “C”. The zone with this group # is in Area C. If in more than one area, all areas
assigned to the zone must be armed before it is in the armed state.
Option 4 Assigned to Area “D”. The zone with this group # is in Area D. If in more than one area, all areas
assigned to the zone must be armed before it is in the armed state.
Option 5 Is a Stay Mode Zone. The zone with this group # is a stay mode zone. If in more than one area, all
areas assigned to the zone must be in stay mode before it is in the armed state.
Option 6 Can be Manually Bypassed. The zone with this group # can be bypassed using the “Bypass” function.
Option 7 Can be Auto-Bypassed. The zone with this group # can be automatically bypassed if unsealed at the
end of the exit delay time.
Option 8 Is a Day Zone. The zone with this group # will cause a Day alarm when the area assigned to the zone is
Disarmed.
ZONE GROUP OPTIONS B
Zone Options B
P421E Zone Group #1 Options B Default 0 1 = Is a 24 Hour Zone
P422E Zone Group #2 Options B Default 0 2 = Is a 24 Hour Fire Zone
P423E Zone Group #3 Options B Default 0 3 = Is a 24 Hour Auto-Reset Zone
P424E Zone Group #4 Options B Default 0 4 = Is a Permanent Day Zone
P425E Zone Group #5 Options B Default 0 5 = Is a Handover Zone
P426E Zone Group #6 Options B Default 0 6 = Is a two Trigger Zone
P427E Zone Group #7 Options B Default 0 7 = Can Arm if zone not “Ready”
P428E Zone Group #8 Options B Default 0 8 = Is a Siren Lockout Zone
P429E Zone Group #9 Options B Default 0
P430E Zone Group #10 Options B Default 0
Option 1 24 Hour Zone. The zone with this group # is active at all times and will trigger the alarm when activated.
If the zone group has an entry delay programmed, the zone has to be in alarm for longer than the delay
time to cause an alarm.
Option 2 24 Hour Fire Zone. The zone with this group # is active at all times and will trigger the alarm when
activated. A 24 Hour Fire zone will cause any programmed alarm outputs to pulse on & off to
differentiate it from a normal 24 hour alarm. The same entry delay function applies as per Option 1
above.
Option 3 24 Hour Auto-reset Zone. The zone with this group # is active at all times and will trigger the alarm
when activated. Unlike the other two options above, when the detector resets, the alarm will also reset
automatically without having to use a code to reset the alarm. The same entry delay function applies as
per Option 1 above.
