Page 21
ZONE GROUP RADIO SENSOR MODE
Zone Radio Mode
P441E Zone Group #1 Radio Mode - Default 0 1 = Crow AE Battery Low
P442E Zone Group #2 Radio Mode - Default 0 2 = Crow AE reed Switch
P443E Zone Group #3 Radio Mode - Default 0 3 = Crow Merlin - Supervised signal ignored
P444E Zone Group #4 Radio Mode - Default 0 4 = Crow Merlin - Supervised signal active
P445E Zone Group #5 Radio Mode - Default 0 5 = Freelink Protocol with Checksum - Supervised
P446E Zone Group #6 Radio Mode - Default 0 6 = Freelink Protocol with Checksum - Non-supervised
P447E Zone Group #7 Radio Mode - Default 0 11 = Ness battery low
P448E Zone Group #8 Radio Mode - Default 0 12 = Ness Reed Switch
P449E Zone Group #9 Radio Mode - Default 0 21 = Electronics Line Cougar PIR
P450E Zone Group #10 Radio Mode - Default 0 31 = Visonic K980W PIR
Option 0 Radio detector type “0”. If the radio device loaded against a zone has no special bits such as tampers/
battery low, etc then leave the radio type as 0. In this case as long as the code received never changes
the panel will always respond correctly to a transmission from the wireless device.
Option 1 AE Protocol. If the wireless device is an AE type then setting option 1 for the PIR will allow it to accept
& 2 the battery low signal correctly when transmitted. If the device is an AE reed switch then setting the
option to 2 will accept both the open and closed signals plus the battery low.
Option 3 Crow Merlin Protocol. If the wireless device is the Crow Merlin PIR then setting option 3 will allow the
& 4 alarm/tamper & battery low signals to be received correctly but the supervised signal will be ignored. By
setting option 4 on all signals from the Merlin including the supervised signal will be monitored correctly.
Option 5 Crow Freelink Protocol. If the wireless device is the Crow Freelink PIR or wireless reed switch then
& 6 setting option 6 will allow the alarm/tamper & battery low signals plus the open & closed signal from the
reed switch to be received correctly but the supervised signal will be ignored. By setting option 5 on all
signals from the Freelink PIR or Reed switch including the supervised signal will be monitored correctly.
Option 11 Ness Protocol. If the wireless device is the Ness PIR then setting the option to 11 will allow the alarm
& 12 and battery low from the PIR to be processed correctly. If the device is the Ness wireless reed switch
then setting the option to 12 will allow the open/close & battery low signals to be processed correctly.
Option 21 Electronics Line Cougar Protocol. If the wireless device is the EL Cougar PIR then setting option 21
will allow the alarm/tamper & battery low signals to be received correctly.
Option 31 Visonic K980W Protocol. If the wireless device is the Visonic K980W PIR then setting option 31 will
allow the alarm/tamper & battery low signals to be received correctly.
ZONE GROUP VOICE MESSAGE #
If you want the panel to play a custom voice message either locally (PA) or over the telephone when reporting a
voice alarm then select the message number at these addresses. The number can be from 1-47. For the message to
work properly it first has to be programmed at address P890E. If the value is left at “0” the panel will play the default
“Canned” message for that group. For the local PA to work options 5-7 must be programmed at addresses P431E-
P440E and to enable the voice alarm reporting the option must be selected for the reporting format for the telephone
number (P703E-P708E).
P451E Zone Group #1 Voice Message # - Default 0
P452E Zone Group #2 Voice Message # - Default 0
P453E Zone Group #3 Voice Message # - Default 0
P454E Zone Group #4 Voice Message # - Default 0
P455E Zone Group #5 Voice Message # - Default 0
P456E Zone Group #6 Voice Message # - Default 0
P457E Zone Group #7 Voice Message # - Default 0
P458E Zone Group #8 Voice Message # - Default 0
P459E Zone Group #9 Voice Message # - Default 0
P460E Zone Group #10 Voice Message # - Default 0
