CubiScan 125 - Measuring Capacities and Physical Specs

Product Description Specifications
CubiScan 125 3
Weight Sensor
Three load cells
Measuring Capacities
Weight Capacity: 0.005 to 50.000 lb (0.002 to 25.000 kg)
Weight Increment: 0.005 lb (0.002 kg)
Physical
Length: 44 in (112 cm)
Width: 44 in (112 cm)
Height: 51 in (130 cm)
Weight: 130 lbs (60 kg)
User Interface
Minimum PC Specifications:
Windows 10/8.1/8/7/XP/95/98/NT/2000, Pentium II processor, 20
megabytes of disk space, screen resolution setting of 800 X 600
Quantronix’s QBIT™ software can be used to interface with the CubiScan
125.
Measurement Range:
Ultrasound
Sensors
Gate Sensors
Length:
2.0 to 24.0 in
(5.0 to 60.0 cm)
0.10 to 18.00 in
(0.2 to 45.0 cm)
Width:
2.0 to 30.0 in
(5.0 to 80.0 cm)
0.10 to 18.00 in
(0.2 to 45.0 cm)
Height:
2.0 to 36.0 in
(5.0 to 90.0 cm)
0.10 to 12.00 in
(0.2 to 30.0 cm)
Measurement
Increment:
0.2 in (0.5 cm) 0.05 in (0.1 cm)
Measurement Time: < 3 seconds < 5 seconds
Object Colors: All colors Opaque
