PAPER THRESHOLD
Threshold value (in percent) for the recognition of the presence of paper by the paper
presence sensor:
30%
D
60% 90%
40% 70%
50% 80%
NOTCH ALIGNMENT
Management of the alignment notch
Disabled
D
= the notch alignment is not performed
Enabled = the notch alignment is performed
NOTCH THRESHOLD
Threshold value (in percent) for the recognition of the presence of notch by the notch
sensor:
30% 60% 90%
40%
D
70%
50% 80%
NOTE: If the “Notch Alignment” parameter is disabled, this parameter is not printed.
NOTCH DISTANCE
“Notch Distance” is the minimum distance (in mm) between the upper edge of ticket
and the notch (see chapter 10).
The numeric value of the distance is made up with the following four parameters
for the setting of three digits (two for the integer part of the number and one for the
decimal part) and of the sign):
NOTCH DISTANCE SIGN
Sign setting:
+
D
= positive distance
- = negative distance
NOTCH DISTANCE [mm x 10]
Setting the digit for tens:
0
D
2 4 6 8
1 3 5 7 9
NOTCH DISTANCE [mm x 1]
Setting the digit for units:
0
D
2 4 6 8
1 3 5 7 9
NOTCH DISTANCE [mm x .1]
Setting the digit for decimals:
0
D
2 4 6 8
1 3 5 7 9
NOTE: For example, to set the notch distance to 15 mm, modify the parameters as follows:
Notch Distance Sign = +
Notch Distance [mm x 10] = 1
Notch Distance [mm x 1] = 5
Notch Distance [mm x .1] = 0
NOTE: If the “Notch Alignment” parameter is disabled, the parameters for the “Notch Distance” are
not printed.
PAPEREND BUFFER
CLEAR
Cleaning mode of the data in receive buffer, if the printing is stopped due to lack of
paper:
Disabled
D
= The data remain in the receive buffer. When the paper runs out, the
printer keeps the remaining data in the receive buffer and prints the
remaining portion of the ticket after that the new paper is loaded.
Enabled = When the paper runs out, all data in the receive buffer are deleted.
5. CONFIGURATION
User manual KPM216HII ETH 45
