SVELTA EMULATION
The ticket features and the alignment parameters, may be modifi ed as follows:
• by using the parameters of the <LHT> command (for more details, refer to the Commands Manual)
• by modifying the Setup.ini fi le (see par.12.9)
• by driver
The following fi gure shows the some of parameters for alignment of the Setup.ini fi le:
• “Ticket X Dimension”
• “Ticket Y Dimension”
• “Notch Width”
• “Notch Distance”
“Ticket X Dimension”
“Ticket Y Dimension”
paper
axis
NON-THERMAL SIDE
Alignment point
Notch
“Notch Distance” “Notch Distance”
“Notch Width” “Notch Width”
10. ALIGNMENT
90 KPM216HII ETH User manual
