D-Link DSL-2888A User Manual

21D-Link DSL-2888A User Manual
Section 4 - Conguration
Click the IPv4 button to see the IPv4 information for each WAN interface. Click the green
arrows to select dierent interfaces.
WAN Interface:
Displays the currently selected interface: Ethernet, DSL, or USB.
Cable Status:
Displays the current cable connection status.
Connection Type:
Displays the network protocol used to obtain an IP address.
Network Status:
Displays the current network connection status.
Connection
Uptime:
Displays the amount of time the connection has been connected.
MAC Address:
The WAN interface's MAC address is listed here.
IP Address:
The WAN IP address is listed here.
Default Gateway:
The default gateway IP address is listed here.
Primary DNS
Server:
Displays the current primary DNS server.
Secondary DNS
Server:
Displays the current secondary DNS server.
Internet
COPYRIGHT © 2016 D-Link
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings Features ManagementHome
Internet DSL-2888A
Connected Clients: 1
USB Device
Internet Connected
Click on any item in the diagram for more information.
DSL/ IPv4 / IPv6
WAN Interface: PTM0 MAC Address: FF:FF:FF:FF:FF:FF
Cable Status: Connected IP Address: 172.17.5.120
Connection Type: Dynamic IP (DHCP) Subnet Mask: 255.255.255.0
Network Status: Connected Default Gateway: 172.17.5.1
Connection Uptime: 1 Day 3 Hour 50 Min 58 Sec Primary DNS Server: 172.17.5.5
Secondary DNS Server: 172.17.5.6
Go to settings
IPv4

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
