D-Link DSL-2888A User Manual

30D-Link DSL-2888A User Manual
Section 4 - Conguration
Ethernet
Your DSL-2888A is equipped with a Gigabit Ethernet WAN port which can be used to connect
to the Internet. This port may be used to connect to other Ethernet based networks. In
order for your DSL-2888A to use Ethernet you must congure the Ethernet Settings, VLAN
Settings, and your IPv4/IPv6 Settings.
WAN Access Type:
Select Residential Gateway to configure Ethernet connection
settings.
Interface:
Select the interface from the drop-down menu. ETH0-ETH5 are
available. The default is ETH0.
Enable Interface:
Select whether to enable or disable this interface.
VLAN Settings
VLAN Tagged:
Enable or disable VLAN tagging.
If you enabled VLAN Tagged, the following options are available:
VLAN ID:
Enter the VLAN ID. The value should be 0, or 0-4079.
VLAN Priority:
Enter the VLAN Priority from the default 0 (lowest) to 7 (highest).
Proceed to IPv4 Settings on page 32 or IPv6 Settings on page 36.
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Internet
SettingsHome Features Management
Internet
Use this section to congure your Internet Connection type. There are several connection types to choose
from Static IP, DHCP, PPPoE, PPTP, L2TP and DS-Lite. If you are unsure of your connection method, please
contact your Internet service provider. Note: If using the PPPoE option, you will need to remove or disable
any PPPoE client software on your computers.
WAN Access Type: Residential Gateway
⌵
Interface:
Eth 0
⌵
Enable Interface:
Enabled
Priority
Save
DSL Prole
VLAN Tagged:
Enabled
VLAN ID:
VLAN Priority:
Disable
⌵
ISP SETTINGS

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
