D-Link DSL-2888A User Manual

43D-Link DSL-2888A User Manual
Section 4 - Conguration
Multiple SSID
The multiple service set identier (SSID) feature will allow you to create temporary zones that
can be used by guests to access the Internet. These zones will be separate from your main
wireless network. You may congure dierent zones for the 2.4 GHz and 5 GHz wireless bands.
In the Settings menu on the bar on the top of the page, click Wireless, then click the Multiple
SSID link.
2.4 GHz / 5 GHz
WLAN Interface:
Select the SSID.
Status:
Enable or disable the selected SSID.
Wi-Fi Name (SSID):
Create a name for your wireless network using up to 32 characters.
Password:
Create a password to use for wireless security. Wireless clients will
need to enter this password to successfully connect to the SSID.
Click Save when you are done.
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Wireless >> Multiple SSID
SettingsHome
Multiple SSID
Features Management
Use this section to congure the wireless settings for your D-Link Router. Please make sure that any
changes made in this section will need to be updated on your wireless device.
2.4GHz
5GHz
WLAN Interface:
SSID1
⌵
Status:
Enabled
Wi-Fi Name (SSID): dlink-2
Password: A_Str0nG_P@ssW0rd!%!
WLAN Interface:
SSID1
⌵
Status:
Enabled
Wi-Fi Name (SSID): dlink-2
Password: A_Str0nG_P@ssW0rd!%!
Wi-Fi
Save
COPYRIGHT © 2016 D-Link

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
