D-Link DSL-2888A User Manual

29D-Link DSL-2888A User Manual
Section 4 - Conguration
VDSL is one of the latest and fastest home broadband technologies. VDSL uses the DSL port
on your DSL-2888A to connect to the Internet. In order for your DSL-2888A to use VDSL, you
must congure the VDSL Settings, your ISP Settings, and your IPv4/IPv6 Settings.
WAN Access Type:
Select VDSL to congure ADSL connection settings.
Interface:
Select the interface from the drop-down menu. PTM0-PTM7 are
available. The default is PTM0.
Enable Interface:
Select whether to enable or disable this interface.
ISP Settings
VLAN Tagged:
Enable or disable VLAN tagging.
If you enabled VLAN Tagged, the following options are available:
VLAN ID:
Enter the VLAN ID. The value should be 0, or 0-4079.
VLAN Priority:
Enter the VLAN Priority from the default 0 (lowest) to 7 (highest).
Proceed to IPv4 Settings on page 32 or IPv6 Settings on page 36.
VDSL
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Internet
SettingsHome Features Management
Internet
Use this section to congure your Internet Connection type. There are several connection types to choose
from Static IP, DHCP, PPPoE, PPTP, L2TP and DS-Lite. If you are unsure of your connection method, please
contact your Internet service provider. Note: If using the PPPoE option, you will need to remove or disable
any PPPoE client software on your computers.
WAN Access Type: VDSL
⌵
Interface:
PTM 0
⌵
Enable Interface:
Enabled
Priority
Save
DSL Prole
VLAN Tagged:
Enabled
VLAN ID:
VLAN Priority:
Disable
⌵
ISP SETTINGS

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
