D-Link DSL-2888A User Manual

56D-Link DSL-2888A User Manual
Section 4 - Conguration
Port Mapping
Number Name Interface Protocol Start Port End Port Open Start Port Open End Port Edit Delete
DSL-2888A HW:V1.0.0 FW:V1.1.43
Features >> Port Forwarding
Port Mapping
Your router helps share a single IP address assigned by your ISP among several clients in your home. Port
forwarding allows trafc requests from a specied application to be directed to a specied client inside.
Settings FeaturesHome Management
Remaining: 15
Add Rule
COPYRIGHT © 2016 D-Link
Port forwarding allows you to specify a port or range of ports to open for specic devices
on the network. This might be necessary for certain applications to connect through the
router. In the Features menu on the bar on the top of the page, click Port Mapping.
If you wish to remove a rule, click on its trash can icon in the Delete column. If you wish to
edit a rule, click on its pencil icon in the Edit column. If you wish to create a new rule, click
the Add Rules button. If you edit or create a rule, the following options will appear:
Create New Rule
Enable:
Enable or disable the rule.
Name:
Enter a name for the rule.
Wan Interface:
Select the interface to apply the rule to.
Protocol:
Select either TCP, UDP, or TCP/UDP.
Start Port:
Enter the starting port range to forward to.
End Port:
Enter the ending port range to forward to.
Open Start Port:
Enter the starting port range to open.
Open End Port:
Enter the ending port range to open.
Click Apply when you are done.
Enable:
Enabled
Wan Interface:
PTM0
⌵
Protocol:
TCP
⌵
Name:
Start Port:
End Port:
Open Start Port:
Open End Port:
Create New Record
Apply

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
