D-Link DSL-2888A User Manual

54D-Link DSL-2888A User Manual
Section 4 - Conguration
Status DestNetwork PrexLen Gateway Metric Interface Edit Delete
DSL-2888A HW:V1.0.0 FW:V1.1.43
Features >> Static Routes >> IPv6
Static Routes
Once connected to the Internet, your router automatically builds routing tables that determine where trafc
should be sent. Static routes can override this process, allowing trafc to be directed to a specic client or
location.
Settings FeaturesHome Management
IPv4
Save
Remaining: 24
Add Route
COPYRIGHT © 2016 D-Link
IPv6
To congure IPv6 rules, on the Static Routes page click IPv6. To return to the main IPv4 static
routes page, click IPv4.
If you wish to remove a rule, click on its trash can icon in the Delete column. If you wish
to edit a rule, click on its pencil icon in the Edit column. If you wish to create a new rule,
click the Add Rules button. Click Save when you are done. If you edit or create a rule, the
following options will appear:
Create New Rule
DestNetwork:
This is the IP address of the router used to reach the specified
destination.
PrexLen:
Enter the IPv6 address prex length of the packets that will take this
route.
Gateway:
Enter your next hop gateway to be taken if this route is used.
Metric:
Enter the metric value for this rule here.
Interface:
Select the interface that the IP packet must use to transit out of the
router when this route is used.
Click Apply and Save when you are done.
DestNetwork:
PrexLen:
Gateway:
Metric:
Interface:
Eth0
⌵
Create New Route
Apply

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
