D-Link DSL-2888A User Manual

22D-Link DSL-2888A User Manual
Section 4 - Conguration
Click the IPv6 button to see the IPv6 information for each WAN interface. Click the green
arrows to select dierent interfaces.
IPv6
WAN Interface:
Displays the currently selected interface: Ethernet, DSL, or USB.
Connection Type:
Displays the network protocol used to obtain an IP address.
Network Status:
Displays the current network connection status.
Connection
Uptime:
Displays the amount of time the connection has been connected.
WAN IPv6
Address:
The WAN IPv6 address is listed here.
Default Gateway:
The default gateway IP address is listed here.
Primary DNS
Server:
The primary DNS server IP address is listed here.
Secondary DNS
Server:
The secondary DNS server IP address is listed here.
Internet
COPYRIGHT © 2016 D-Link
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings Features ManagementHome
Internet DSL-2888A
Connected Clients: 1
USB Device
Internet Connected
Click on any item in the diagram for more information.
DSL / IPv4 / IPv6
WAN Interface: PTM0 WAN IPv6 Address: Not Available
Connection Type: DJC{v6 Default Gateway: Not Available
Network Status: Connected Primary DNS Server: Not Available
Connection Uptime: 1 Day 3 Hour 50 Min 58 Sec Secondary DNS Server: Not Available
Go to settings

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
