D-Link DSL-2888A User Manual

44D-Link DSL-2888A User Manual
Section 4 - Conguration
Network
Network Settings
LAN IP Address:
Enter the IP address of the router for this interface. The default IP
address is 192.168.1.1.
If you change the IP address, once you click Save, you will need
to enter the new IP address in your browser to get back into the
conguration utility.
Subnet Mask:
Enter the subnet mask of this interface. The default subnet mask is
255.255.255.0.
Local Domain
Name:
Enter the domain name (optional).
Enable DNS Relay:
Disable for devices on your network to perform DNS lookups directly
with your ISP. If enabled, your computers will use the router as a DNS
server.
Advanced Settings - DHCP Server
Status:
Enable or disable the DHCP server.
DHCP IP Address
Range:
Enter the starting and ending IP addresses for the DHCP server’s IP
assignment.
Note: If you statically (manually) assign IP addresses to your computers
or devices, make sure the IP addresses are outside of this range or you
may have an IP conict.
This section will allow you to change the local network settings of the router and to congure
the DHCP settings. In the Settings menu on the bar on the top of the page, click Network.
Click Advanced Settings... to expand the list and see all of the options.
DHCP Server
Advanced Settings
Status:
Enabled
DHCP IP Address Range:
192.168.1.
100
to 192.168.1.
254
DHCP Lease Time: 86400 minutes
IPv4 Multicast Streams:
Enabled
IPv6 Multicast Streams
Enabled
COPYRIGHT © 2016 D-Link
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Network
SettingsHome
Network
Features Management
Use this section to congure the network settings for your device. You can enter a name for your device in
the management link eld, and use the link to access web UI in a web browser. Recommend to change the
management link if there are more than one D-Link devices within the network.
Network Settings
Advanced Settings ...
LAN IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
Local Domain Name: localhost
Enable DNS Relay:
Enabled
Save
Advanced Settings ...
IPv6 Settings
WAN Interface: Eth0
⌵
My Internet Connection is: Auto Conguration (SLAAC/DHCPv6)
LAN IPv6 ADDRESS SETTINGS
Enable DHCP-PD:
Enabled
LAN IPv6 Link-Local Address: fe80::1
ADDRESS AUTOCONFIGURATION SETTINGS
Enable Automatic IPv6 Address Assignment:
Enabled
Autoconguration Type: Stateful DHCPv6
⌵
IPv6 Advertisement Lifetime: minutes

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
