D-Link DSL-2888A User Manual

24D-Link DSL-2888A User Manual
Section 4 - Conguration
DSL-2888A
Click on the DSL-2888A icon to view details about the router and its wireless settings.
Here you can see the router’s current wireless networks and passwords, as well as the local
area network MAC, IPv4, and IPv6 addresses.
To recongure the network settings, click the Go to settings link, from the Settings menu
at the top of the page, select Network. Refer to page 44 for more information.
To recongure the wireless settings, click the Go to settings link, from the Settings menu
at the top of the page, select Wireless. Refer to page 41 for more information.
COPYRIGHT © 2016 D-Link
Wi-Fi 2.4GHz
Status: Enabled
Wi-Fi Name (SSID): dlink-DSL-2888A
Password: A_Str0nG_P@ssW0rd!%!
DSL-2888A
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings Features ManagementHome
Internet DSL-2888A
Connected Clients: 1
USB Device
Internet Connected
Click on any item in the diagram for more information.
IPv4 Network
MAC Address: FF:FF:FF:FF:FF:FF
Router IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
IPv6 Network
Link-Local Address: FF00::FF00:FF00:FF00:FF00
Router IPv6 Address: 2001:B021:23:10::1/64
DHCP-PD: Disabled
Go to settings
Go to settings
Wi-Fi 5GHz
Status: Enabled
Wi-Fi Name (SSID): dlink-DSL-2888A 5Ghz
Password: A_Str0nG_P@ssW0rd!%!
Multiple SSID(2.4GHz)
Multiple SSID(5GHz)
Go to settings

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
