D-Link DSL-2888A User Manual

31D-Link DSL-2888A User Manual
Section 4 - Conguration
WAN Access Type:
Select USB to congure USB connection settings.
Interface:
Select the interface from the drop-down menu.
Enable Interface:
Select whether to enable or disable this interface.
ISP Settings
Country: Select your country.
ISP: Select your ISP. A number of ISP conguration settings are pre-
programmed into the DSL-2888A for convenience. If you don't see
your ISP or wish to use manual settings, choose Not Listed.
PIN Code: Enter your PIN code.
Dial Number: Enter the Dial Number.
APN: Enter the APN.
Username: Enter your username.
Password: Enter your password.
There is no further conguration. Click Save when you are done.
The DSL-2888A supports USB mobile broadband adapters. You can connect a mobile
broadband adapter and share your cellular network connection with your home network.
For a list of supported adapters, visit www.dlink.com.
This page provides conguration settings for your USB mobile broadband connection.
Refer to your mobile broadband adapter's documentation for setup instructions and ISP
for conguration information. In most cases, the process is plug and play and requires no
further conguration.
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Internet
SettingsHome Features Management
Internet
Use this section to congure your Internet Connection type. There are several connection types to choose
from Static IP, DHCP, PPPoE, PPTP, L2TP and DS-Lite. If you are unsure of your connection method, please
contact your Internet service provider. Note: If using the PPPoE option, you will need to remove or disable
any PPPoE client software on your computers.
WAN Access Type:
USB
⌵
Interface:
USB 0
⌵
Enable Interface:
Enabled
Priority
Save
DSL Prole
Country:
New Zealand
⌵
ISP:
Not Listed
⌵
PIN Code:
Dial Number:
APN:
Username:
Password:
ISP SETTINGS
COPYRIGHT © 2016 D-Link
USB

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
