D-Link DSL-2888A User Manual

47D-Link DSL-2888A User Manual
Section 4 - Conguration
SharePort
This page will allow you to set up access to les on an external USB device plugged into the
router. You can do this through the local network or from the Internet using either a web
browser or an app on your smartphone or tablet. In the Settings menu on the bar on the
top of the page, click SharePort.
DLNA Media Server
Windows File Sharing (SAMBA)
Web File Access
Status:
Enabled
Direct Links:
http://shareport.local/
https://shareport.local/
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Shareport
SettingsHome
SharePort
Features Management
SharePort allows you to share photos, music, movies and les simply by connecting a USB drive to your
router. Access your les locally and remotely using the free mydlink SharePort app for your iOS or Android
devices, or access them on a computer through the SharePort Web Access. The built-in Digital Living
Network Alliance (DLNA) media server allows you to stream multimedia content to any DLNA compliant
devices such as smart TVs and games consoles.
Create User
Status:
Enabled
DLNA Media Server: DSL-2888A_DMS
Status:
Enabled
Windows File Sharing: Use created accounts
⌵
Save
COPYRIGHT © 2016 D-Link
DLNA Media Server
Status:
Enable or disable the DLNA media server function, allowing connected
clients access to media les over the network.
DLNA Media
Server:
Choose a name for your DLNA media server so that it can be found.
Windows File Sharing (SAMBA)
Status:
Enable or disable the Windows File Sharing function, allowing
connected clients access to media les over the network.
Windows File
Sharing:
Choose either Allow all users to access (no password) or Require
router’s admin password to specify whether the router’s password
will be required for access.
Web File Access
Web File Access:
Enable or disable remote access to les stored on a USB device
plugged into the router through a web browser.
Direct Links:
This area will display the HTTP and HTTPS links to connect to your
SharePort drive through a web browser from a device on your
network.
Click Save when you are done.

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
