D-Link DSL-2888A User Manual

55D-Link DSL-2888A User Manual
Section 4 - Conguration
Status Host Name Server Address Interface Edit Delete
Remaining: 10
Add Record
COPYRIGHT © 2016 D-Link
DSL-2888A HW:V1.0.0 FW:V1.1.43
Features >> Dynamic DNS
Dynamic DNS
Dynamic Domain Name Service allows your router to associate an easy-to-remember domain name such as
[YourDomainName].com with the regularly changing IP address assigned by your Internet Service provider.
This feature is helpful when running a virtual server.
Settings FeaturesHome Management
Save
Enable Dynamic DNS:
Enabled
Dynamic DNS
Most Internet Service Providers (ISPs) assign dynamic (changing) IP addresses. Using a
Dynamic Domain Name Server (DDNS) service provider, people can enter your domain name
in their web browser to connect to your server no matter what your IP address is. Owners
of D-Link routers can use the dlinkdns service. In the Features menu on the bar on the top
of the page, click Dynamic DNS.
Enable Dynamic
DNS:
Enabling dynamic DNS reveals further conguration options.
If you Enabled Dynamic DNS, click Add Record and congure the following options are
available:
Server Address:
Enter the address of your DDNS server, or select one from the drop-
down menu.
Host Name:
Enter the host name that you registered with your DDNS service
provider.
User Name:
Enter your DDNS username.
Password:
Enter your DDNS password.
Interface:
Select an interface from the drop-down menu to apply the DDNS
rule to.
Click Apply and Save when you are done.
Server Address:
dyndns.com dyndns.com
⌵
Host Name:
User Name:
Password:
Interface:
PTM0
⌵
Create New Record
Apply

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
