58D-Link DSL-2888A User Manual
Section 4 - Conguration
Name:
MAC Address:
Week: Sun Mon Tue Wed Thu Fri Sat
Time: - (hh:mm-hh:mm)
Access to Internet:
Apply
DSL-2888AHW:V1.0.0FW:V1.1.43
Schedule
Some features, such as the rewall and website lters, can be turned on or off based on a schedule. One
common use of schedules is to control access to the Internet by a specied device during specied time
periods.
Settings FeaturesHome Management
Management >> Schedule
Save
Time
Name MAC Address Schedule Edit Delete
Remaining: 10
Add Rule
COPYRIGHT © 2016 D-Link
Parental Control / Schedule
Some router functions can are controlled by can be set according to a pre-congured
schedule. To create, edit, or delete schedules click Parental Control / Schedule, from the
Time page. To return to the Time page, click Time.
If you wish to create a new rule, click the Add Rules button. If you wish to edit a rule, click
on the corresponding pencil icon in the Edit column. If you wish to remove a rule, click on
the corresponding trash can icon in the Delete column. Click Save when you are done. If
you edit or create a rule, the following screen will appear:
Enter the name of your schedule in the Name eld.
Enter the MAC address of the PC you which to apply the rule to.
Select the days of the Week to apply the rule to.
Enter the Time to begin and start the rul.
Select Access to Internet if you wish to enable or disable Internet access for this device.
Click Apply and Save when you are done.
