5D-Link DSL-2888A User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 3 4 5 62 7
1 DSL Port Connects to an DSL-enabled telephone line and with the supplied microsplitter.
2 Gigabit LAN Ports (1-4) Connects to Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
3 Reset Button
To reset the device to its factory default settings, use a paper clip to press and hold the reset button for
3 seconds.
4 Gigabit WAN Port Connects to Ethernet WAN devices.
5 USB 2.0 Port Connects to USB ash drives to share content or USB mobile dongles for Internet connectivity.
6 Power Connector Connector for the supplied power adapter.
7 Power Button Press the power button to power the DSL-2888A on and o.
