D-Link DSL-2888A User Manual

40D-Link DSL-2888A User Manual
Section 4 - Conguration
Priority
Internet Fail Over
Primary Internet
Connection:
Select the primary Internet connection to use. The options are PTM_/
ATM_, which is the xDSL connection; Eth_0 and Eth1-Eth5 if enabled,
which are the Ethernet WAN interfaces provided by Residential
Gateway mode; and USB0, which is a USB connected modem.
Secondary
Internet
Connection:
Select the secondary backup, Internet connection to use in the event
the primary Internet connection fails.
Tertitary
Backup Internet
Connection:
Select the third backup, Internet connection to use in the event the
primary and secondary Internet connection fails.
Click Save when you are done.
From this page you may congure your Internet failover priority. In the event that your
primary Internet connection method fails, this device can automatically fall back to using a
secondary or tertiary connection in order to maintain Internet connectivity.
DSL-2888A HW:V1.0.0 FW:V1.1.43
Settings >> Internet >> Priority
SettingsHome Features Management
Priority
Congure your Internet fail over priority. In the event that your primary Internet connection method fails, this
device can automatically fall back to using a secondary or tertiary connection in order to maintain Internet
connectivity. From this page you may congure your Internet failover priority.
Primary Internet Connection PTM0
⌵
Secondary Internet Connection
Eth0
⌵
Tertitary Backup Internet Connection Not Available
⌵
Internet
Save
DSL Prole
Internet Fail Over
COPYRIGHT © 2016 D-Link

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
