D-Link DSL-2888A User Manual

64D-Link DSL-2888A User Manual
Section 4 - Conguration
DSL-2888A HW:V1.0.0 FW:V1.1.43
Statistics
This page gives you various statistics about data transmitted and received by your router through the
Internet, on your wired network (LAN), and through your wireless networks.
Settings FeaturesHome Management
Management >> Statistics
Clear
Internet LAN Wi-Fi 2.4GHz Wi-Fi 5GHz
100 KB/s
75 KB/s
50 KB/s
25 KB/s
0 KB/s
Total Packets Total KBytes(s) KByte/sec
Sent: 0 0 0 Session
Received: 0 0 0 0
COPYRIGHT © 2016 D-Link
Statistics
On the Statistics page you can view the amount of trac that has passed through the router
on the WAN, LAN, and wireless segments.
In the Management menu on the bar on the top of the page, click Statistics.
You can view the Internet, LAN, Wi-Fi 2.4 GHz, or Wi-Fi 5 GHz statistics by clicking on the
respective tabs at the top. The graph will update in real time. To clear the information on
the graph, click Clear.
The trac counter will reset if the device is rebooted.

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
