D-Link DSL-2888A User Manual

49D-Link DSL-2888A User Manual
Section 4 - Conguration
Features
DSL-2888A HW:V1.0.0 FW:V1.1.43
Features >> Firewall Settings >> IPv4/v6 Rules
Settings FeaturesHome Management
Save
Advanced
Firewall Settings
Your router’s high-performance rewall feature continuously monitors Internet trafc, protecting your network
and connected devices from malicious Internet attacks.
Add Rule
COPYRIGHT © 2016 D-Link
LAN-WAN
Number Enable IP Range/Port Range(Source) IP Range/Port Range(Dest) Protocol Device Name Action
WhiteList

BlackList

Add Rule
Number Enable IP Range/Port Range(Source) IP Range/Port Range(Dest) Protocol Device Name Action
WAN->LAN WhiteList

BlackList

Firewall
Enabled
IPv4/IPv6 Rules
The IPv4/IPv6 Rules page contains advanced options that let you set rules to restrict IP trac
across your network or from your network to the Internet. Click the Enable/Disable button
to enable or disable the rewall. Disabling the rewall is not recommended.
Use the drop-down menu to select whether you want to WhiteList to allow only the trac
below or BlackList to block the rules your create.
If you wish to remove a rule, click on the corresponding trash can icon in the Delete column.
If you wish to edit a rule, click on the corresponding pencil icon in the Edit column. If you
wish to create a new rule, click the Add Rule button. Click Save when you are done. If you
edit or create a rule, the following options will appear:
Create New Rule
IP Version:
Select either IPv4 or IPv6.
Connection:
Select the interface to apply the rewall rule to.
Enable:
Enable or disable this rule.
Source IP:
Enter the source IP address range that the rule will apply to.
Sourc Port:
Enter the source port to apply the rule to.
Dest IP:
Enter the destination IP address range that the rule will apply to.
Dest Port:
Enter the destination port to apply the rule to.
Click Save when you are done.
IP Version:
IPv4
⌵
Connection:
-
⌵
Enable:
Enabled
Protocol:
ALL
⌵
Source IP
Source Port
Dest Port
Dest Port:
Create New Rule
Apply

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
