D-Link DWL-8600AP User Manual

Configuring SNTP Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 105
D-Link UWS User Manual
Summer Time Recurring Configuration
Clicking the Recurring check box indicates that the configuration is to be repeated every year. When you select
Recurring, the fields shown in the following table occur.
Figure 36: Summer Time Recurring Configuration
Table 31: Summer Time Recurring Configuration Fields
Field Description
Summertime Enable or disable summer time mode.
Recurring Select the check box to indicate that the configuration is to be repeated every year.
Location This field displays only when the Recurring check box is selected. The summer time
configuration is predefined for the United States and European Union. To set the summer
time for a location other than the USA or EU, select None.
Offset Set the number of minutes to add during summer time in the range 0 to 1440.
Zone Set the acronym of the time zone to be displayed when summer time is in effect. The range
is 0 to 4 characters.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
