ACL Interface Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 372
D-Link UWS User Manual
Assigning an ACL to an Interface
1. Open the ACL Interface Configuration page.
2. Select the interface from the Slot/Port field to which you want to bind the ACL.
3. Select the type of ACL in the ACL Type field.
4. Select the ACL ID or name to bind to the interface.
5. Specify the priority in the Sequence field.
6. Click Submit.
The ACL is attached to the specified interface(s).
Removing an ACL from an Interface
If an ACL is bound to an interface, the Remove button appears on the page when you select the interface from
the Slot/Port menu. To remove the ACL from the interface, select the type of ACL to remove and its ID or name,
and then click Remove.
Note: Whenever an ACL is assigned on a port or LAG, flows from that ingress interface that do not
match the ACL are matched to the default rule, which is Drop unmatched packets.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
