Configuring MLD Snooping
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 230
D-Link UWS User Manual
• If you make any changes to the page, click Submit to apply the new settings to the system.
• To disable the MLD Snooping admin mode on a VLAN, select the VLAN from the VLAN ID field and click
Delete.
Multicast Router Configuration
The switch can dynamically learn of an attached multicast router, or you can configure a switch port as a
multicast router interface. Use the MLD Snooping Multicast Router Configuration page to configure an
interface as a static multicast router interface.
To access the MLD Snooping Multicast Router Configuration page, click LAN > L2 Features> MLD Snooping >
Multicast Router Configuration in the navigation tree.
Figure 135: MLD Snooping Multicast Router Configuration
• If you enable or disable multicast router configuration on an interface, click Submit to apply the new
settings to the switch.
Multicast Router Expiry Time Enter the amount of time in seconds that a switch waits for a query to be
received on an interface before the interface is removed from the list of
interfaces with multicast routers attached. The range is 0 to 3600 seconds. A
value of 0 indicates an infinite time-out; i.e., no expiration.
Table 119: MLD Snooping Multicast Router Configuration Fields
Field Description
Slot/Port Select the physical or LAG interface to display.
Multicast Router Set the multicast router status:
• Enabled: The port is a multicast router interface.
• Disabled: The port does not have multicast router configured.
Table 118: MLD Snooping VLAN Configuration Fields (Cont.)
Field Description
