D-Link DWL-8600AP User Manual

Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 277
D-Link UWS User Manual
DAI ARP ACL Configuration
Use the DAI ARP ACL Configuration page to add or remove DAI ARP ACLs.
To display the DAI ARP ACL Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI ARP
ACL Configuration in the navigation tree.
Figure 174: Dynamic ARP Inspection ARP ACL Configuration
• Click Add to create a new ARP ACL.
• Click Delete to remove the configured ARP ACL entry you selected in the Remove column.
• Click Refresh to refresh the page with the most current data from the switch.
Table 157: Dynamic ARP Inspection ARP ACL Configuration
Field Description
ARP ACL Name Use this field to create a new ARP ACL for Dynamic ARP Inspection. The name can be 1 to
31 alphanumeric characters in length.
ARP ACL List Displays by name a list of all the configured ARP ACLs. Use the Remove column, to select
the particular ACLs you want to delete.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
