D-Link DWL-8600AP User Manual

Configuring DNS
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 145
D-Link UWS User Manual
Configuring DNS
You can use these pages to configure information about DNS servers the network uses and how the switch/
router operates as a DNS client.
Global Configuration
Use this page to configure global DNS settings and to view DNS client status information.
To access this page, click LAN > Administration > DNS Client > Global Configuration.
Figure 66: DNS Global Configuration
• If you change any settings, click Submit to send the information to the router.
Table 58: DNS Global Configuration Fields
Field Description
Admin Mode Select Enable or Disable from the pulldown menu to set the administrative
status of DNS Client. The default is Disable.
Default Domain Name Enter the default domain name for DNS client messages. The name should be
no longer than 255 characters. When the system is performing a lookup on an
unqualified hostname, this field is provided as the domain name (e.g., if
default domain name is .com and the user enters hotmail, then hotmail is
changed to hotmail.com to resolve the name).
By default, no default domain name is configured in the system.
Retry Number Enter the number of times to retry sending DNS queries. The valid values are
from 0 to 100. The default value is 2.
Response Timeout Enter the number of seconds to allow a DNS server to respond to a request
before issuing a retry. Valid values are 0 to 3600. The default value is 3.
Domain List Enter a domain list to define the domain to use when performing a lookup on
an unqualified hostname. Each name must be no more than 256 characters.
Multiple default domain names can be configured using the default domain-
name list.
If there is no domain list, the default domain name configured is used.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
