D-Link DWL-8600AP User Manual

Configuring Time Ranges
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 144
D-Link UWS User Manual
Click Submit to create the time range entry. Configuration changes take effect immediately. These changes will
not be retained across a power cycle unless a save is performed.
Periodic Time Range Entry
Applicable Days Specify the day(s) when the time entry occurs:
• Daily — Has the same start and end time every day
• Weekdays — Has the same start and end time Monday through Friday
• Weekdays — Has the same start and end time on Saturday and Sunday
• Days of the Week — Select the day of the week when the entry starts and
stops. You do not need to use the same day of the week for the start and
end time.
Start Day (Periodic Days of Week only) Select the day the time range entry starts. To
select multiple days, hold the CTRL key and click the days.
Start Time Specify the time when the entry begins. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
End Day (Periodic Days of Week only) Select the day the time range entry ends.
End Time Specify the time when the entry ends. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
Absolute Time Range Entry
Absolute Start Date and Time Select the check box to configure the date and time when the time range entry
begins.
Start Month Select the month when the time entry begins.
Start Date Select the day of the month when the time entry begins.
Start Year Select the year when the time entry begins.
Start Time Specify the time when the entry begins. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
Absolute End Date and Time Select the check box to configure the date and time when the time range entry
ends.
End Month Select the month when the time entry ends.
End Date Select the day of the month when the time entry ends.
End Year Select the year when the time entry ends.
End Time Specify the time when the entry ends. The time is based on a 24-hour clock.
For example, 6:00 PM is 18:00.
Table 57: Time Range Entry Configuration
Field Description

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
