D-Link DWL-8600AP User Manual

Managing LLDP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 272
D-Link UWS User Manual
LLDP-MED Remote Device Information
This page displays information on LLDP-MED information received from remote clients on the selected local
interface. To display this page, click LAN > Monitoring > LLDP Status > LLDP-MED > Remote Device
Information in the navigation tree.
Figure 170: LLDP Remote Device Information
Table 153: LLDP-MED Remote Device Information Fields
Field Description
Local Interface Specifies the list of all the ports on which LLDP-MED is enabled.
Remote ID Specifies the remote client identifier assigned to the remote system.
Capability Information Specifies the supported and enabled capabilities that were received in MED
TLV on this port:
• Supported Capabilities: Specifies supported capabilities that were
received in MED TLV on this port.
• Enabled Capabilities: Specifies enabled capabilities that were received in
MED TLV on this port.
• Device Class: Specifies device class as advertised by the device remotely
connected to the port.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
